5x50night vision binocular II |
RG88 |
RG66 |
RG55 |
5X50 night vision binocular |
RG77 6X50 |
|
|
 | Lens magnification ,x | 3 | 5 | | 0bjective lens diameter, mm | 44mm | 50mm | | Lens system | 59mm F1.2 | 88mm F1.7 | | FOV at distance 190m/200yards, m | 197/60 | 138/42 | | Focus range, yards | 1.5 to infinity | 1.0 to infinity | | field of view ,degree | 30 | 18 | | Eye relief, mm | 15 | 15 | | Exit pupil diameter, mm | 6 | 6 | | Eyepiece Dioper adjustment, dptr | +4/-4 | +4/-4 | | Overall dimensions, L×H×W, mm | 180x80x50 | 200x80x50 | | Weight, g | 310 | 460 | | Power supply, v | AA battery (one by 3.6V) | AA battery (one by 3.6 V) | | Battery life IR off, | Up to 70 | Up to 70 | | Battery life IR on, | hour Up to 20 | hour Up to 20 | | Effective Distance | | | | Detection range, m | 200/150 | 220/175 | | IR power, mw | 25≤ | 25≤ | | IR wavelength, nm | 850 | 850 | | IR effective distance, m | 25 | 25 | | Environmental Data | | | | IP standard of water-resistance | IPX4 | IPX4 | | Humidity,% | 93 | 93 | | Operating temperature, ℃ | -30°to+45° | -30°to+45° | | Storage temperature, ℃ | 0°to+60° | 0°to+60° |


|
