ED80 |
ED65 |
|
|
| MODELS SPEC. | 22-65X100 | | SWZ721 Eyepiece | | 01 | POWER | 倍 率 | 有效倍数 | 22x | 65x | | 02 | OBJ.LENS DIA. | 物镜直径 | mm | 有效直径 | 100mm | | 03 | TYPE OF PRISM | 棱镜类别 | Type / Material | 类别及材料 | Porro/BAK4 | | 04 | PRISM COATING | 棱镜镀膜 | Yes / No | 是或否 | No | | 05 | NUMBER OF LENS | 透镜组数 | Pieces & Groups | 共多少片及分多少组 | 9pieces6groups | | 06 | LENS COATING | 透镜镀膜 | CL/FC/BMC/FBMC | 部分或全部或多层膜 | FBMC | | 07 | FOCUS SYSTEM | 调焦系统 | Cent. / Ind. / Fix | 中调或分调或定焦 | Cent. | | 08 | FOCUSING LENS | 调焦透镜 | Eye. / Obj. / Int. | 目镜或物镜或内调 | Int. | | 09 | EXIT PUPIL DIAMETER | 出瞳直径 | mm | 4.6 | 1.54 | | 10 | EXIT PUPIL DIST. | 出瞳距离 | mm | 17 | | 11 | FIELD OF VIEW | 视 场 | ANGLE | 角度 | 1.8° | 0.9° | | 12 | Ft / 1,000Yds | 尺 | 94.2 ft | 48ft | | 13 | M / 1,000M | 米 | 31.4m | 16m | | 14 | MIN.FOCAL LENGTH | 最近焦距 | M / Ft. | 米 / 尺 | 7m/21ft | | 15 | RELATIVE BRIGHTNESS | 相对亮度 | 21.2 | 2.4 | | 16 | TWLIGHT INDEX | 黄昏指数 | 46.9 | 80.6 | | 17 | RESOLUTION | 分辨率 |  ≤2.2" | | 18 | DIOPTER SYSTEM | 视差补偿 | 左或右的目镜或物镜 | | 19 | DIOPTER COMP. | 视差度数 | ±Optic.Degree | | 20 | INTERPUPILLARY DIST. | 目镜相距 | mm | 最阔及最窄时 | | 21 | ZOOM SYSTEM | 变焦系统 | Type & Location | 线性或分段 | 线性 | | 22 | WEATHER PROOF | 全 天 候 | Yes / No | Yes | | 23 | WATER PROOF | 防水结构 | Depth / Time | 深度及时间 | 1.5m/3min | | 24 | NITROGEN FILLED | 氮气充存 | Yes / No | 有或无 | Yes | | 25 | EYECUPS SYSTEM | 目罩结构 | Rubber / Pop-up / Twist-up | 可反接橡胶/拉出/旋出 | Twist-up | | 26 | POUCH | 软 包 | Yes / No-Mat'l. | 有或无及材料 | Yes | | 27 | STRAP | 手 带 | Yes / No-Mat'l. | 有或无及材料 | No | | 28 | CLEANING CLOTH | 清 洁 布 | Yes / No | 有或无 | Yes | | 29 | SILICA GEL | 干 燥 剂 | Yes / No | 有或无 | Yes | | 30 | UNIT DIAMENSION | 产品尺寸 | mm | 485x115x165 | | 31 | UNIT WEIGHT | 产品重量 | gm / oz. | 1,830g | | 32 | GIFT BOX SIZE | 彩盒尺寸 | mm | 490x125x200 | | 33 | PIECES PER INNER CARTON | 内箱件数 | Pieces / Size | 只数及尺寸 | | INNER CARTON SIZE | 内箱尺寸 | | 34 | PIECES PER SHIPPING CARTON | 装箱件数 | Pieces | 4PCS/CTN | | 35 | SHIPPING CARTON SIZE | 装箱尺寸 | Size | cm | 56x56x25.5 | | 36 | GROSS WEIGHT | 毛 重 | Kg. / Pound | 9kgs | | 37 | NET WEIGHT | 净 重 | Kg. / Pound | 8kgs |     |
